KF-30GW房间空调器的设计

 KF-30GW房间空调器的设计

摘要:空调器一般包括制热与制冷型、单冷型等,但本次设计主要针对热带气候地区,所以仅仅考虑一个单冷型机型。空调器分别是对区域和?房间与空间提供除湿热的空气等空气经过处理,单冷型空调只能提供出冷风或者热风,它是循环空气并且净化空气的装置,它包括制冷和除湿两种作用。设计内容分别有:冷凝器设计、压缩机选型计算、制冷剂的选用、蒸发器的设计计算、其他辅助型设备选型。此次的课题是在基础为热带气候下设计的,其中参数有这些:蒸发温度为5摄氏度,冷凝温度50摄氏度、膨胀阀前液体温度40摄氏度、过冷度8摄氏度、吸气温度15摄氏度、室外干球温度35摄氏度、湿球温度24摄氏度、室内干球温度27摄氏度、湿球温度19摄氏度。通过对机组整体的设计大致可以得出这个结论:室内机组采用挂壁式大大的节省了室内的有限空间;压缩机则也是应用适用于中国电源制式的特制的压缩机,其中压缩机的型号则是ZRD42KC-PFJ,选用R22作为压缩机的制冷剂,翅片管热交换器则是用冷凝器和蒸发器,蒸发器型号为 30K4-11型轴流风机,强对流地直接蒸发式蒸发器,蒸发器传热面积为 8.82W/(㎡?K),冷凝器型号为YSF56-2轴流风机,其中冷凝器则在换热方面的实际面积是23.78W/(㎡?K)。
关键词:家用空调器;分体挂壁式空调器;其他辅助设备

一、选题简介、意义
本次课题是关于KF-30GW房间空调器的设计,KF-30GW空调器是单冷式的挂壁分体空调。本次毕业设计任务是完成家装单冷空调系统负荷设计计算,分析并确定空调系统设计方案和主要设备的选型。要求各项设计计算正确,图纸等符合要求,按时完成各项任务。
随着人民生活水平的提高,人们对居住环境的要求也随之提高,不仅要提高室内环境的舒适度,也要节能、环保。所以本次课题主要设计一款用来调节空气的湿度、气流速度、洁净度等舒适性参数,为人们的生活和生产活动创造适宜的室内环境。
本次设计及计算将运用我大学三年所学到的知识并且查阅相关暖通的书籍,将数据做到精准,一些疑问将请教老师,做到勤能补拙。

二、课题综述(课题研究,主要研究的内容,要解决的问题,预期目标,研究步骤、方法及措施等)
1、主要研究内容:
   KF-30GW空调器调节空气的湿度、气流速度、洁净度等舒适性参数,为人们的生活和生产活动创造适宜的室内参数。
2、要解决的问题:
   KF-30GW房间空调器的实测冷量不应小于额定制冷量的95%,实测功耗不应大于额定耗功的110%,额定能效比EER不小于3.2。
3、预期目标
   KF-30GW房间空调器能达到一个适宜的房间湿度、房间温度、房间通风量的标准。
4、研究步骤:
   ①室内外空气设计参数;
   ②风管设计;
   ③设备选型与配置;
   ④负荷计算;
   ⑤空气调节系统;
   ⑥气流组织
5、方法及措施:
   查阅相关文献资料,通过书上设计规范和请教老师来完成设计。
Design of KF-30GW room air conditioner
Abstract:Air conditioners usually include heating and refrigerating type, single cooling type, but this design is mainly for tropical climates, so we only consider a single cooling type. The air conditioner is to provide the air and other air to the room and space, which can only provide cold air or hot air. It is a device for circulating air and purify the air. It includes two functions of refrigeration and dehumidification. The design contents are condenser design, compressor type selection, refrigerant selection, evaporator design and calculation, and other auxiliary equipment selection. The topic is designed on the basis of the tropical climate, with these parameters:evaporation temperature of 5 degrees Celsius, condensing temperature 50 degrees Celsius, expansion valve before liquid temperature 40 degrees Celsius,supercooling 8 degrees Celsius, suction temperature 15 degrees Celsius, outdoor dry ball temperature 35 degrees Celsius, wet ball temperature 24 degrees Celsius, indoor dry ball temperature 27 The temperature of the Celsius and the wet ball is 19 degrees centigrade. Through the overall design of the unit, we can roughly draw the conclusion that the indoor unit uses the hanging wall type to greatly save the limited room space; the compressor is also the special compressor applied to the power supply in China, in which the type of compressor is ZRD42KC-PFJ, and R22 is selected as the refrigerant and fin tube of the compressor. The heat exchanger is a condenser and evaporator, the evaporator model is 30K4-11 axial fan, the direct evaporation evaporator with strong convection, the heat transfer area of the evaporator is 8.82W/ (K), the condenser model is the YSF56-2 axial fan, and the actual area of the condenser in the heat transfer is 23.78W/ (K).
Key words: household air conditioners; split wall air conditioners;finned tube heat exchangers
