制袋机纠偏及系统设计
摘 要
随着我国加入WTO，塑料软包装行业正在向全球化方向发展。国内人民生活水平的提高，也给塑料软包装行业带来了无限商机。塑料软包装制袋机也随之蓬勃发展。塑料袋是人们日常生活中，最为常用的工具，消耗量非常大，可以说方便袋在人们的生活中无处不在。从19世纪50年代，英国人帕克斯发明并制造了第一个塑料袋之后，塑料袋就占据了不可替代的地位。例如：超市、商店、工厂、饭店等等，已经涉及到不同的领域。国产制袋机结合国内市场需要，充分考虑用户的具体情况，适应用户的不同需求，设计开发出一种多功能全自动的制袋机。通过该课题的研发工作，使学生能够正确运用所学课程的基本理论和有关知识，学会设计方案的拟定、比较、分析及进行必要的计算, 提高学生应用工程技术设计手册、标准以及编写文件的能力。在这样的背景下，本次毕业设计针对塑料制品加工的这个主题，参考各种设备资料，并利用AUTOCAD等现代工具软件，进行了塑料印刷生产线中的全自动制袋机纠偏的设计,其技术指标达到较高的生产率和的分选精度。相比起传统印刷方法，这种基于纵封原理进行作业的塑料加工机器在机械化、加工精度以及自动化程度等方面都大大提升。从而极大地提高了塑料精加工产品的产量和质量。
本设计是全自动制袋机纠偏的一部分。全自动制袋机纠偏是服务于包装行业的一种制袋设备。现在市面上主要有以下几种制袋机：
1 . 专用三边封低速,中速,高速三种制袋机.
2 . 专用中封低速,中速,高速三种制袋机.
3 . 三边封,中封两用低速,中速,高速三种制袋机.
4 . 高速三边封的自立,拉链制袋机.
5 . 医药特用制袋机.
还有一些四边封,等少见有特殊用途的制袋机.但他们有一个共同点就是要对一些能热封复合的塑料薄膜进行横封和纵封.使原来的薄膜变成袋子.下面就主要针对这类机上的一重要部件------纵封热封部件进行一些基本的说明以及工作原理等.
关键词 塑料制品 ； 制袋设备 ； 机械化 ； 自动化
Abstract
Joins WTO along with our country, the plastic processed foods profession is developing to the globalized direction.。Domestic living standards enhancement, also gave the plastic processed foods profession to bring the infinite opportunity.。Plastic processed foods bag-making machine also along with it vigorous development.。The plastic bag is in the people daily life, the most commonly used tool, the consumption is big, may say that facilitates the bag in people's life ubiquitous. From the 1850s, after English Pax invented and has made the first plastic bag, the plastic bag occupied the unreplaceable status.。For example: Supermarket, store, factory, hotel and so on, already involved to the different domains. The domestically produced bag-making machine union domestic market need, considered fully the user the special details, the adaptation user's different demand, the design develops one kind of multi-purpose completely automatic the bag-making machine. Through this topic's research and development work, enables the student to utilize correctly studies the curriculum the elementary theory and the related knowledge, the academic society design proposal draws up, the comparison, to analyze and to carry on the essential computation, enhances the student application engineering technology design handbook, the standard as well as compilation document ability. Under such background, this graduation project needle plastic products processing selection's this subject, refers to each kind of equipment material, and using modern tool softwares and so on AUTOCAD, has carried on the plastic printing production line's completely automatic bag-making machine's design, its technical specification achieves the high productivity and separation precision. Compares the traditional printing method, this kind carries on the work based on the template principle the plastic processing machine in aspects and so on mechanization, working accuracy as well as automaticity greatly promotes. Thus raised the plastic precision work product output and the quality enormously.
This design is a completely automatic bag-making machine's part. The completely automatic bag-making machine is serves the packing profession one system bag equipment. Now in the market condition mainly has the following several kind of bag-making machines:
1. Special-purpose trilateral seals the low speed, the medium speed, high speed three kind of bag-making machines.
2. Special-purpose seals the low speed, the medium speed, high speed three kind of bag-making machines.
3. Trilateral seals, seals the dual purpose low speed, the medium speed, high speed three kind of bag-making machines.
4. High speed trilateral seals supporting oneself, zipper bag-making machine.
5. The medicine uses the bag-making machine especially. also has some nearby the fours to seal, and so on has the special use bag-making machine rarely. But they have a common ground are must to carry on to some be able the heat-seal compound plastic film seal horizontally with vertical seal. Causes the original thin film to turn the bag. Below mainly aims at this kind of machine on an important part------Vertical seals the heat-seal part to carry on some basic explanations as well as the principle of work and so on
Keywords Plastic products ；Makes the bag equipment ；Mechanization ； Automation
目 录
摘 要 I
Abstract II
第 1 章 塑料制品加工机械综述 2
1.1 国内外制袋机的比较 2
1.1.1 国内外制袋机在大小功能上的比较 2
1.1.1.1 国内外制袋机在质量价格上的比较 3
1.1.2 机电一体化产品的设计步骤 5
1.1.2.1 机电一体化产品的优点和效益 6
第 2 章 自动制袋机纠偏的设计与计算 8
2.1 自动制袋机纠偏的分类 8
2.1.1 自动制袋机纠偏的组成 8
第 3 章 结论 16
第 4 章 致谢 17
参考文献 18
附录一 19
附录二 24
参考文献
1 王淑华、许鑫编著.制袋机结构原理与故障排除. 北京：化学工业出版社，2004
2申永胜编著. 机械原理教程. 北京：清华大学出版社，1999
3牛鸣岐、王保民、王振甫编著. 机械原理课程设计手册. 重庆：重庆大学出版社，2001
4石永刚、徐振华编著. 传动机构设计. 上海：上海科学技术出版社，1995
5刘昌祺、牧野洋、曹西京编著. 凸轮机构设计. 北京：机械工业出版社，2005
6冯瑞乾编著. 印刷概论. 山西：西北工业大学出版社，2000
7许文才、智文广编著. 现代机械. 北京：印刷工业出版社，1999
8邓普君编著. 现代印刷技术概论. 江苏：苏州大学出版社，2003
9王裕德发明. 多用印刷机. 山东：85 1 02357，1985
10濮良贵. 机械设计. 北京： 高等教育出版社出版， 2003.2
11崔甫主编. 校直理论与参数计算. 北京： 机械工业出版社， 2002.8
12马一林.中国机械设计大典[M].江西：科学技术出版社,1990
13马一林.机械设计原理[M].江西：高等教育出版社,1992
14吴宗泽.机械设计与课程设计[M].北京：高等教育出版社,1998
15黄华梁.机械设计基础第二版[M].北京：北京中央广播电视大学出版社,1990
16吴宗泽.机械设计禁忌500例[M].北京：机械工业出版社，1988
17吴宗泽.机械设计实用手册[M].北京：化学工业出版社，1990
18王玉新. 机构创新设计方法学. 天津：天津大学出版社，1996年.112～116
19JJ.杰克（美）. 机械与机构的设计原理. 北京：机械工业出版社，1985年.201～203
20罗洪量. 机械原理课程设计指导书. 北京：高等教育出版社，1986年.102～105
21Ball and Roller Screus. Engineering Material and Design. 1975
.Mechanial Drive(Rference Issue). Machine Design. S(2). 1980
