西门子PLC与数控机床的现场总线通信设计
摘要:伴随着现场总线不断地更新,其在工业控制的领域应用也变的十分普遍,此中Profibus-DP总线是一种使用普遍、宽泛和不依赖于生产商的现场总线 ,它合用于可编程序控制器和现场的I/O设备两者间的迅速通讯,它是系统中最成熟的现场总线之一,可用于生产自动化,以满足分布式I/O与现场设备之间的高速数据。任务书中要求配置双插槽,配置Profibus-DP从站的数控机床与西门子S7-300组成现场总线,即组成Profibus-DP通信网络,实现西门子PLC对数控机床的控制及监控。通过以往数据可以知道,西门子PLC Profibus-DP总线通过组态,可以方便的得到设备状态和运行数据 。
关键词:西门子PLC ;Profibus-DP;数控机床
Design of fieldbus communication between SIEMENS PLC and NC machine tool
Abstract: Constantly updated with field bus and its application in the field of industrial control have become widespread, the profibus-dp fieldbus is a kind of use in general, broad and does not depend on producers of fieldbus, it is applicable to the scene of the programmable controller and I/O devices between the rapid communication, it is one of the most mature of field bus in the system, can be used in the production of automation, in order to meet the distributed I/O and the high-speed data between field devices. Demand of commitments in the double slot, profibus-dp slave station configuration of nc machine tools with Siemens S7-300 fieldbus, namely of profibus-dp communication network, Siemens PLC control and monitoring of nc machine tools. Through the past data can be know, Siemens PLC and profibus-dp fieldbus through configuration, easy to get the equipment state and running data.
Keyword: Siemens PLC; profibus-DP;CNC machine tools
目录
第一章 绪论 2
1.1 现场总线技术起源与应用 2
1.2 数控机床系统的起源与应用 2
1.3 对西门子PLC通信的了解 4
1.3.1对PROFIBUS-DP通信的了解 4
1.3.2对OPC通信的了解 5
1.4 建立PROFIBUS-DP网络 5
第二章 系统总体设计 7
2.1起源与应用 7
2.2系统结构 7
第三章 FANUC数控系统与PROFIBUS-DP从站配置 9
3.1在电脑上安装 FANUC编程软件 9
3.2 在PMC上设计程序并通信 9
3.3 在PROFIBUS-DP上设定参数 9
3.3.1转换PMC格式和 计算机文件格式 10
3.3.2设置 PMC数据 10
3.4 机床参数状态 11
第四章 SIMATIC S7-300硬件组态与编程 12
4.1 在程序上加入GSD文件 12
4.2 在S7-300上添加硬件组态 13
4.3 在S7-300上用软件编程 18
4.4 回顾与总结 19
致谢 21
参考文献 22
参考文献
1.陆胜,刘锬.基于PROFIBUS-DP的SIMATICS7-300通讯及网络组态研究.机床与液压,2007.09
2.郭秋香,张兄华.电气应用.2011,16:87-90
3.张爱红,FANUC数控系统连接调试与维护.北京:人民邮电出版社,2010.7
4.吴丽,刘玉斌.西门子S7-300PLC基础与应用.北京:机械工业出版社,2011.3
5.北京FANUC.梯形图语言编程说明(B-61863C),2001
6.顾京.数控机床加工程序编制.北京:机械工业出版社,2013.1
7..FANUC0iD_0iMateD连接说明书(功能篇)(B-64303CM-1_01)
8.FANUCPMC参数的格式.BEIJING-FANUC
9.北京发那科机电有限公司.FANUCPMC设计与编程培训教程.北京:高等教育出版社,2011.11
