清洗机静电箱的设计

清洗机静电箱的设计
清洗机静电箱的设计
摘要:外部移动气缸气缸带动外部毛刷上下移动,清扫周转箱外部;内部移动气缸带动内部毛刷上下移动:通用清洗机装置由PLC控制系统、双轴联动系统和传送带转送及气动系统组成。外部移动,从而清扫周转箱内部。同时,内外部毛刷都可以快速更换。通用清洗机的启动装置的运动过程:周转箱由人工放置导轮上,然后人工推送到指定位置,系统通电后按下启动按钮传送带开始运行,当位于传送带初始端的光电传感器检测到有物体通过时,清扫开始,先左右外部清洗,后前后内部清洗,如此重复完成一个过程。在此过程中可根据物体的大小来设置或用示教功能来设置速度的参数。
关键词:PIC;内部;外部;传送;导轮
The design of electrostatic box cleaning machine
Abstract: The external moving cylinder drives the external brush moves up and down, cleaning the turnover box outside; internal cylinder drives the internal brush on mobile general washing machine by PLC control system, biaxial linkage system and a conveyor belt transfer and pneumatic system. The external movement, thus cleaning internal turnover box. At the same time, the inside outside brush can be replaced quickly. The motion controller of washing machine: the turnover box by manually placed guide wheel, and then manually pushed to the specified location, the system after power press the start button belt running, when the photoelectric sensor is located on the conveyor belt initial end is detected when the object passes through, cleaning, first external cleaning, after internal cleaning, repeat the completion of a process. The parameters in this process can be based on the size of the object to set
Keywords: PLC, internal and external, transfer, idler pulley

目录
摘要···················································Ⅰ
Abstract................................................Ⅱ第一章 绪论........................................... ...1
 1.1机电一体化概论....................................... 1
 1.2 通用清洗机的背景及意义............................. .1
 1.3 通用清洗机的研究现状............................... .2
 1.4 通用的研究内容..................................... .2
第二章 通用清洗机的总体设计............................ ..3
 2.1 通用清洗机的整体设计思路............................ 3
 2.2 通用清洗机系统的组成................................ 5
第三章 静电箱通用清洗机的硬件选型及电器控制要求...........8  3.1 硬件选型及介绍......................................8 3.2 电器控制要求..................................... ..12
第四 通用清洗机的电气控制系统的设计......................13
 4.1通用清洗机控制系统设计思路......................... .13
 4.2 对静电箱清洗机的要求.............................. .14
 4.3 静电箱清洗机的扩展与预测.......................... .15
 4.4 PLC控制程序设计.....................................16
 4.5 主要的故障与排除.................................. .27
 4.6操作说明........................................... .27
第五章 毕业设计小结及致谢............................... 28
 毕业设计小结........................................... 39
 致谢................................................... 30
 参考文献…………………………………………………………… .31

参考文献
[1]西门子公司.s7-200 可编程控制器系统手册.[M].西门子公司,2008

[2]向晓汉,黎雪芬,张爱红等.PLC 控制技术与应用.[M].北京:清华大学出版社,2010.

[3]向晓汉等.电气控制与PLC 技术.[M].北京:人民邮电出版社,2011.

[4]倪森寿.机械技术基础.[M].北京:人民邮电出版社,2012.

[5]俞云强等.传感器与检测技术.[M].北京:高等教育出版社,2008.

[6] 欧姆龙综合产品样本. [M].欧姆龙有限公司出版

[7]  曹英等.传感器与检测技术. [M].电子工业出版社  2011-09-01

[8] 冯英等.继电器与可编程控制器. [M].科学出版社 2011-09-03
