LED发光板的结构设计
摘要：最近一些年来，发光二极管（LED）以其环保、节能、全固态、长寿命等特点受到了广泛的关注，特别是大功率高亮度的LED在固态照明应用领域里的技术突破，使人们对其取代传统光源的希望越来越强。从目前的发展情况来看，大功率LED要真正实现产普及化和业化仍然受到诸多因素的制约，其中，结构设计过程中的散热效果和可靠性相对传统光源不高是目前大功率LED应用中普遍存在的问题。
本文从理论方面向大家介绍了与LED相关的许多知识：
①介绍了LED的结构和发光原理，并选取了一些与LED紧密相关的特性加以说明。
②介绍了LED芯片的制备工艺、LED芯片的结构以及芯片的结构设计工艺的流程。
③重点解决大功率LED在结构设计时遇到的各种问题，并给出对应的解决方法。本文就其中的几个重点加以讲述，包括结构设计的可靠性问题、取光率问题以及散热问题。
关键词：LED发光板；结构设计；可靠性；结构设计
Abstract：In recent years, light emitting diode (LED) for its environmental protection, energy saving, all solid, long life and other characteristics has been widespread concern, especially high-power high brightness LED technology breakthroughs in the field of solid-state lighting applications, so as to affirm replace conventional light sources hope getting stronger. From the current development situation, the production of high-power LED to realize universal and industrialization remain constrained by many factors, which encapsulates the process of cooling effect and reliability compared to conventional light sources is not high-power LED applications widespread problem.
From theory to introduce a lot of knowledge and LED-related:
① The structure and light-emitting principle of LED, and select a number of closely related with LED characteristics will be described.
② The preparation process of LED chip architecture and chip packaging process flow LED chips.
③ focused on solving the problems of high-power LED package encountered when, and gives the corresponding solutions. This article describes just a few of them focus on reliability issues, including packaging, light extraction efficiency issues and heat.
Keywords: high power LED, packaging, reliability, heat-release performance
