摘要:此次设计是针对杭州市某小区平层地暖系统工程设计,其中房子的建筑面积大约为100m2,其中供暖面积为90m2,其中主卧、客厅、主卫、餐厅、书房、次卧均为低温热水地面辐射供热。设计参数:冬季室内温度大约为20OC,在设计中,地暖管采用的是德国进口的曼派PE - RT管道,管间距150mm,室内温控器选择德国曼瑞德,型号为E51.713。

关键词:低温热水地面辐射供热。

Abstract:This design is aimed at the design of a flat floor heating system in a residential district of Hangzhou. The building area of the house is about 100 m2, and the heating area is 90 m2. The main bedroom, living room, main guard, restaurant, study and secondary bedroom are all ground radiation heating with low temperature hot water. Design parameters: The indoor temperature in winter is about 20OC. In the design, the Manpai PE-RT pipe imported from Germany is used as the ground heating pipe. The pipe spacing is 150mm. The indoor temperature controller is selected from Mandred, Germany. The model is E51.713.

Key words:Low Temperature Hot Water Ground Radiation Heating.

目录

一、 前言 1

二、 工程概况与设计依据 2

2.1工程概况 2

2.2设计依据 2

三、 设计条件 3

四、建筑墙体的传热系数 4

五、采暖设计的热负荷 5

5.1 维护结构的耗热量 6

5.2 冷风渗透耗热量 10

5.3冷风侵入耗热量 13

六、采暖的系统设计方案 14

6.1热水供暖系统的分类和选型 14

6.2低温热水地面辐射供暖系统及其构造的说明和选型 16

6.3地暖系统的主要设备和其附件 19

七、供暖系统的水力计算 20

7.1 热水供暖系统水力计算的基本公式 21

7.2水力计算结果与结论 23

八、结论 24

九、总结和体会 25

十、谢辞 26

十一、参考文献 27
