电力系统短路电流计算与分析
摘 要
短路电流将引起下列严重后果：短路电流往往会有电弧产生，它不仅能烧坏故障元件本身，也可能烧坏周围设备和伤害周围人员。巨大的短路电流通过导体时，一方面会使导体大量发热，造成导体过热甚至熔化，以及绝缘损坏；另一方面巨大的短路电流还将产生很大的电动力作用于导体，是导体变形或损坏。电力系统正常运行的破坏多半是由短路故障引起的。发生短路时，系统从一种状态剧变到另一种状态，并伴随产生复杂的暂态现象。所谓短路，是指一切不正常的相与相之间或相与地发生通路的情况。在三相系统中，可能发生的短路有：三相短路、两相短路、两相短路接地和单相接地短路。
【关键词】 短路、对称短路、不对称短路
Calculation and analysis of short circuit current in power system
Abstract
Short circuit current will cause the following serious consequences: short circuit current tend to produce arc, which can not only burn out fault element itself may also burn the surrounding equipment and harm the surrounding personnel. A huge short-circuit current through a conductor, on the one hand will make a lot of heat conductor, caused by conductor overheat and melt, and insulation damage; another huge short-circuit current will also produce great role electric power to the conductor, conductor deformation or damage. The destruction of the normal operation of the power system is mostly caused by short circuit fault. When a short circuit occurs, the system changes from one state to another, and is accompanied by a complex transient phenomenon. The so-called short, refers to the occurrence or pathway and all abnormal phase condition. In the three phase system, the short circuit is likely to occur: Three - phase short circuit, two phase short circuit, two phase short circuit and single phase to ground fault.
[Key words] short circuit, symmetrical short circuit, asymmetrical short circuit
