摘   要:齿轮油泵是通过一对参数和结构相同的渐开线齿轮的相互滚动啮合,将油箱内的低压油升至能做功的高压油的重要部件。是把发动机的机械能转换成液压能的动力装置。齿轮油泵由于其结构简单、制造容易、成本低,因此在国内是应用相当广泛的能用机械产品,而以外啮合泵应用最广。本分析报告中主要对油泵的齿轮、轴承、后盖、泵体进行分析,经过对零件的分析、测量和讨论,画出零件手绘图,;再经过查阅和分析有关参考书、手册、图表等技术资料,作出以下零件的功能、材料、尺寸、受力和生产方式的分析,从国外先进技术和经验中吸取长处、积极探索,在设计中培养自己分析问题、解决问题的能力,力争独立思考、勇于创新,为今后的工作打下一个良好的基础。
齿轮油泵的发展历史:公元前100年左右就有了类似齿轮油泵的工业用具,据说是古希腊工匠克特西比乌斯发明的灭火泵是一种最原始的活塞泵,已具备典型活塞泵的主要元件,但活塞泵只是在出现了蒸汽机之后才得到迅速发展。
  1840~1850年,美国沃辛顿发明泵缸和蒸汽缸对置的,蒸汽直接作用的活塞泵,标志着现代活塞泵的形成。然而随着需水量的剧增,从20世纪20年代起,低速的、流量受到很大限制的活塞泵逐渐被高速的离心泵和回转泵所代替.国内的第一台齿轮泵生产在原泊头市齿轮油泵总厂,在2005年已正式改名为河北恒盛泵业股份有限公司。早在1588年就有了关于四叶片滑片泵的记载,以后陆续出现了其他各种回转泵,但直到19世纪回转泵仍存在泄漏大、磨损大和效率低等缺点。
  1689年,法国物理学家帕潘发明了四叶片叶轮的蜗壳离心泵。但更接近于现代离心泵的,则是1818年在美国出现的具有径向直叶片、半开式双吸叶轮和蜗壳的所谓马萨诸塞泵。现在的离心泵已经可以现实了自吸,多吸。立式以及卧式多种用途。1851~1875年,带有导叶的多级离心泵相继被发明,使得发展高扬程离心泵成为可能。

关键词:齿轮轴承、油泵后盖、泵体、零件、分析





Gear pump parts modeling and structure desig
Abstract:  to gear pump through mutual meshing of a pair of involute gearparameters and structure of the same, the tank
An important component of low pressure in the oil to the high-pressure oil canwork. The engine is to convert mechanical energy into hydraulic energy powerdevice. Gear pump because of its simple structure, easy manufacture, low cost,so it is applied in China can use a wide range of mechanical products, and the most widely used outside gearing pump. Analysis of the main oil pump gears,bearings, a back cover, a pump body of the analysis report, after analysis, the parts of the measurement and discussion, draw the parts drawing,; by and analysis of relevant reference books, manuals, diagrams and other technical information, make the following parts of function, material, size, analysis of forceand the mode of production, and actively explore the strengths, learn fromforeign advanced technology and experience, to develop their ability to analyze problems, to solve the problems in the design, and strive to independent thinking,the courage to innovate, to lay a good foundation for future work.
The development history of the gear pump: BC 100 years or so has industrial appliance similar gear pump, fire pump is said to be the ancient Greek craftsmeninvented by Kurt Siby Lucius is one of the most primitive of the piston pump, has the main components of a typical piston pump, but after the piston pump is only in the present of the steam engine was developed rapidly.
From 1840 to 1850, American Worthington invented the pump cylinder and steam cylinder boxer, direct effect of the steam piston pumps, marked the formation of modern piston pump. However, with the drastic increase of water demand, from twentieth Century since 20, piston pump speed, large limit to the flow are gradually replaced by high-speed centrifugal pumps and rotary pump.The domestic first gear pump production of Botou city in the original gear pumpgeneral factory, in 2005 has been officially renamed Hebei Hengsheng pumpLimited by Share Ltd.
. As early as 1588 had a 4-vane pump records, later have a variety of other rotary pump, but it was not until nineteenth Century that still exist in rotary pump leakage, wear the shortage and low efficiency.
In 1689, French physicist Papin invented 4-impeller volute centrifugal pump. But the more close to the modern centrifugal pump, is in 1818, appeared in the United States with straight radial blades, semi - open double suction impeller and volute so-called Massachusetts pump. Centrifugal pump is realistic self absorption, multi suction. Vertical and horizontal multiple purposes. From 1851 to 1875, multistage centrifugal pumps with guide vane were invented, which make the development of high lift centrifugal pump is possible.
Keywords gear bearing, pump cover, a pump body, parts, analysis
.
