手柄座零件机械加工工艺和钻孔（Φ10+00.015）夹具设计
摘要：手柄座零件是车床操纵部分的组成零件之一，该手柄座的作用相当于一个连杆，车床外部手柄的运动是通过车床手柄座传递到车床内部实现人为对机床的操纵。在设计中，主要目的是根据零件选择合理的工艺路线，然后制定出一套可行的夹具。本文涉及两大部分，第一部分是对手柄座零件的分析及工艺规程的制定；第二部分是对于零件中的两次钻孔加工采用不同的定位、夹紧方式进行典型夹具的设计。通过设计一方面使我们更进一步熟悉了产品加工设计的全过程，在制定加工方案的时候，充分考虑其经济性和可行性。另一方面通过对手柄座零件的机械加工工艺规程设计和钻孔用夹具设计，试图找出一种简单、实用的加工方法，以供生产同类零件的企业参考。
关键字：手柄座；工艺；夹具
Handle Parts Machining Process and Typical Fixture Design
Abstract：Handle seat parts is one of the component parts of lathe parts manipulation, the handle seat ACTS as a connecting rod. Movement is handle by lathe external handles to the lathe internal implementation artificial control for machine tools. In the design, the main task is according to the parts during the design and calculation, including processing machine tools, spindle speed, the three elements of cutting the reasonable selection of the processing technology, as well as the typical fixture design. This article involves two parts, the first part is the analysis of the handle seat parts and processing procedures. Two drilling in the second part is for parts with different way of positioning, clamping typical fixture design. Through the design on the one hand, make us more familiar with the whole process of the product processing design, at the time of processing plan formulation, give full consideration to its economical efficiency and feasibility. On the other hand through the handle parts of the machining process planning design and drilling fixture design, trying to find out a simple and practical processing methods, to provide the reference for the manufacture of similar parts.
Key words: The handle seat; process; fixture
目录
一 绪论...................................................................1
1.1前言..................................................................1
1.2题目背景及意义........................................................1
1.3国内外相关研究情况....................................................1
二 零件的分析.............................................................3
2.1 生产纲领..............................................................3
2.2 零件的作用............................................................3
2.3 零件的要求............................................................4
2.4 零件的工艺分析........................................................4
2.5 零件表面加工方法的选择................................................5
三 工艺规程设计...........................................................8
3.1 毛坯制造..............................................................8
3.2 基面选择..............................................................8
3.2.1 粗基准选择..........................................................8
3.2.2 精基准选择..........................................................8
3.3 制定工艺路线..........................................................8
3.3.1 工艺路线方案一......................................................8
3.3.2 工艺路线方案二......................................................9
3.3.3 工艺方案分析.......................................................10
3.4．加工余量确定.........................................................11
3.5 确定切削用量及基本工时...............................................11
四 钻孔夹具设计..........................................................23
4.1 任务提出.............................................................23
4.2 定位方案及定位装置的设计.............................................23
4.2.1 定位方案确定.......................................................23
4.2.2 定位元件及装置设计.................................................24
4.2.3 确定最佳定位方式...................................................25
4.2.4 定位误差分析.......................................................25
4.2.5 定位元件型号尺寸和安装方式.........................................25
4.3 加紧方案确定.........................................................26
五 结论..................................................................29
参考文献.................................................................30
