事故车车身修复工艺设计
摘要:汽车工业作为我国的支柱产业,发展日新月异,深入到社会生活的各个领域,汽车技术的发展,新材料广泛使用,都使现代汽车与传统汽车有巨大的差距,这样也给现代汽车碰撞维修带来新的难题。自1940年前后出现无梁结构汽车以来,为适应汽车行业的经济性、环保性的需求,各种汽车的车身钢板重量越来越轻,钢板厚度越来越薄材料的合金成分越来越复杂。现代轿车大都采用无骨架承载式车身,发生碰撞后,车身变形较为严重,在车身的维修过程中,车身数据的测量、车身拉伸修复及应力消除是在钣金工工作中经常遇到的问题。
关键字:承载式车身;车身变形;拉伸修复;车身数据测量;应力消除
The Repairing Process Design of Accident Car Body
Abstract: Auto industry as a pillar industry of our country, the rapid development and deep into every field of social life, the development of automobile technology, new material widely used, make modern cars and traditional car there is a huge gap, it also bring new problems to modern car collision repair. Since no car beam structure appeared before and after 1940, in order to adapt to the needs of the economy, environmental protection of the automotive industry, all kinds of automobile body sheet is more and more light weight, thickness of steel plate is more and more thin, material of the alloy composition is more and more complex. Modern cars are mostly using frameless monocoque body, after the collision, the deformation of car body is relatively serious, in the process of car maintenance, car body measuring data, body stretching repair and stress relief is often encountered problem in the sheet metal work.
The keywords: Monocoque body, body deformation, tensile repair, data measured ,stress relieving
目 录 _Toc21660
第一章 车身修复基础知识 3
第一节 作业与防护 3
第二章 车身轻微损伤的修复 6
第一节 前翼子板的修复 6
第二节 车门面板的修复 6
第三章 车身严重损伤的修复 10
第一节 损伤诊断 10
第二节 车身矫正 10
第三节 车身严重损坏的维修方案 12
第四节 车身更换 14
总结 20
致谢 21
参考文献 22
参考文献
马云贵,谭本忠 汽车钣金教材 机械工业出版社 2008
高宏伟 汽车钣金[M] 机械工业出版社 2007
刘森 汽车钣金工修复技术 北京 金盾出版社 2001
邹群 汽车维修钣金工 中国劳动社会保障出版社 2003
冯培林 汽车钣金维修技术 化学工业出版社 2010
